High Voltage High Speed Amplifier/Piezo Driver AHVAPN2000V20MA

Part Number 1-4 5-8 9-12 13-16 17-20 ≥21 stock Buy Now Datasheet
AHVAPN2000V20MA
Under Development
$1999 $1949 $1899 $1849 $1799 $1749 0 buy now Buy Now Datasheet
Click to View

MAIN FEATURES

Built-in High Voltage Converter

High Current Capability: Up to 20mA

High Slew Rate: 2000V/µs

Bandwidth: Up to 100kHz

Wide Output Voltage Range: VOUT = 10~2kV@VIN = 24V

Offset Voltage Range: -10V~10V

Compact Size: 181.5(L)*149(W)*38.3(H) mm

Weight: 2.2lb (1.0kg)

APPLICATIONS

This high voltage amplifier, AHVAPN2000V20MA, can be used for driving Piezo and other high voltage loads.

DESCRIPTION

The AHVAPN2000V20MA is an electronic module for amplifying an analog input voltage into a high voltage output. It comes with a high voltage DC-DC converter, which converts the 24V input voltage into a 10 to 2kV output voltage. The analog output voltage can swing almost from 10 to 2kV when it is powered by a 24V power supply. There is three LEDs indicating if the amplifier works properly. We also have one piezo driver module, which can drive the large Piezo at a high speed rate and it is widely popular among our customers.
