12V Input High Voltage Power Supply

Click to View

FEATURES
High precision
Full modulation range on output voltage
Linear regulation
Input control voltage: 0~5V
Control Voltage Range at VTRL Port: 0 to 5V
Input Control Voltage: 0 to 5V
High Efficiency: >70% @full load
Electronic Shutdown Control Available
Zero EMIs and Good Heat Sinking by Metal Enclosure

The high voltage output can be set by connecting the CTRL lead (white color) to a POT's central tap or modulated by an AC signal ranging from 0V to 5V.
While this power supply operates efficiently without external heat sinking, enhancing its heat dissipation capacity through mounting on a metal plate with a robust thermal connection and ensuring proper ventilation is advisable, especially if the implementation does not entail significant extra costs. These measures contribute to maintaining the module's surface temperature below the specified maximum of 55°C, ultimately boosting its performance and longevity.

We can design and manufacture customized products based on customers' requirements.

Selection Guide for DC-DC High Voltage Power Supply.

Note – Reference Voltage

The reference voltage is for powering a potentiometer (≥10KΩ) to adjust the high-voltage output. Do NOT use it to power other devices.

Stock is shown live in our online store.
Click the button, or click a cart icon in the Buy Now column to see the stock of each model.

Check Live Stock

Part Number	Output Voltage	Max. Output Current	Input Voltage	Unit Price	Dimension (mm)
AHV12V500V1MAW	500V	1mA	11V ~ 13V	$119	82×55×28
AHV12V500V2MAW	500V	2mA	11V ~ 13V	$129	82×55×28
AHV12V500V5MAW	500V	5mA	11V ~ 13V	$139	82×55×28
AHV12V500V10MAW	500V	10mA	11V ~ 13V	$149	82×55×28
AHV12V500V20MAW	500V	20mA	11V ~ 13V	$169	82×55×28
AHV12V500V50MAW	500V	50mA	11V ~ 13V	$189	82×55×28
AHV12V1KV1MAW	1kV	1mA	11V ~ 13V	$129	82×55×28
AHV12V1KV2MAW	1kV	2mA	11V ~ 13V	$135	82×55×28
AHV12V1KV3MAW	1kV	3mA	11V ~ 13V	$139	82×55×28
AHV12V1KV5MAW	1kV	5mA	11V ~ 13V	$149	82×55×28
AHV12V1KV10MAW	1kV	10mA	11V ~ 13V	$189	82×55×28
AHV12V1KV20MAW	1kV	20mA	11V ~ 13V	$199	82×55×28
AHV12V1500V1MAW	1500V	1mA	11V ~ 13V	$155	82×55×28
AHV12V1500V2MAW	1500V	2mA	11V ~ 13V	$159	82×55×28
AHV12V1500V3MAW	1500V	3mA	11V ~ 13V	$165	82×55×28
AHV12V1500V5MAW	1500V	5mA	11V ~ 13V	$179	82×55×28
AHV12V1500V10MAW	1500V	10mA	11V ~ 13V	$209	82×55×28
AHV12V2KV1MAW	2kV	1mA	11V ~ 13V	$139	82×55×28
AHV12V2KV3MAW	2kV	3mA	11V ~ 13V	$159	82×55×28
AHV12V2KV5MAW	2kV	5mA	11V ~ 13V	$169	82×55×28
AHV12V2KV10MAW	2kV	10mA	11V ~ 13V	$199	82×55×28
AHV12V2500V1MAW	2500V	1mA	11V ~ 13V	$142	82×55×28
AHV12V2500V3MAW	2500V	3mA	11V ~ 13V	$159	82×55×28
AHV12V2500V5MAW	2500V	5mA	11V ~ 13V	$169	82×55×28
AHV12V3KV1MAW	3kV	1mA	11V ~ 13V	$145	82×55×28
AHV12V3KV2MAW	3kV	2mA	11V ~ 13V	$149	82×55×28
AHV12V3KV3MAW	3kV	3mA	11V ~ 13V	$159	82×55×28
AHV12V3KV5MAW	3kV	5mA	11V ~ 13V	$169	82×55×28
AHV12V3KV10MAW	3kV	10mA	11V ~ 13V	$269	100×90×30
AHV12V4KV1MAW	4kV	1mA	11V ~ 13V	$149	82×55×28
AHV12V4KV2R5MAW	4kV	2.5mA	11V ~ 13V	$159	82×55×28
AHV12V4KV5MAW	4kV	5mA	11V ~ 13V	$189	82×55×28
AHV12V5KV1MAW	5kV	1mA	11V ~ 13V	$155	82×55×28
AHV12V5KV2MAW	5kV	2mA	11V ~ 13V	$169	82×55×28
AHV12V5KV4MAW	5kV	4mA	11V ~ 13V	$199	82×55×28
AHV12V6KV1MAW	6kV	1mA	11V ~ 13V	$159	82×55×28
AHV12V6KV3MAW	6kV	3mA	11V ~ 13V	$199	82×55×28
AHV12V7KV1MAW	7kV	1mA	11V ~ 13V	$169	82×55×28
AHV12V7KV2MAW	7kV	2mA	11V ~ 13V	$239	82×55×28
AHV12V8KV1MAW	8kV	1mA	11V ~ 13V	$179	82×55×28
AHV12V8KV2R5MAW	8kV	2.5mA	11V ~ 13V	$249	82×55×28
AHV12V9KV1MAW	9kV	1mA	11V ~ 13V	$189	82×55×28
AHV12V10KV1MAW	10kV	1mA	11V ~ 13V	$219	82×55×28
AHV12V25KV1MAW	25kV	1mA	11V ~ 13V	$459	140×100×55
AHV12V30KVR5MAW	30kV	0.5mA	11V ~ 13V	$459	140×100×55
AHV12VPN1KV1MAW	1kV/−1kV	1mA	11V ~ 13V	$199	140×100×55
AHV12VPN5KV2MAW	5kV/−5kV	2mA	11V ~ 13V	$339	140×100×55
AHV12VPN10KV1MAW	10kV/−10kV	1mA	11V ~ 13V	$659	140×100×55
AHV12VN500V1MAW	−500V	1mA	11V ~ 13V	$119	82×55×28
AHV12VN500V2MAW	−500V	2mA	11V ~ 13V	$129	82×55×28
AHV12VN500V5MAW	−500V	5mA	11V ~ 13V	$139	82×55×28
AHV12VN500V10MAW	−500V	10mA	11V ~ 13V	$149	82×55×28
AHV12VN500V20MAW	−500V	20mA	11V ~ 13V	$169	82×55×28
AHV12VN500V50MAW	−500V	50mA	11V ~ 13V	$189	82×55×28
AHV12VN1KV1MAW	−1kV	1mA	11V ~ 13V	$129	82×55×28
AHV12VN1KV2MAW	−1kV	2mA	11V ~ 13V	$135	82×55×28
AHV12VN1KV3MAW	−1kV	3mA	11V ~ 13V	$126	82×55×28
AHV12VN1KV5MAW	−1kV	5mA	11V ~ 13V	$135	82×55×28
AHV12VN1KV10MAW	−1kV	10mA	11V ~ 13V	$169	82×55×28
AHV12VN1KV20MAW	−1kV	20mA	11V ~ 13V	$199	82×55×28
AHV12VN1500V1MAW	−1500V	1mA	11V ~ 13V	$135	82×55×28
AHV12VN1500V2MAW	−1500V	2mA	11V ~ 13V	$139	82×55×28
AHV12VN1500V3MAW	−1500V	3mA	11V ~ 13V	$145	82×55×28
AHV12VN1500V5MAW	−1500V	5mA	11V ~ 13V	$159	82×55×28
AHV12VN1500V10MAW	−1500V	10mA	11V ~ 13V	$189	82×55×28
AHV12VN2KV1MAW	−2kV	1mA	11V ~ 13V	$139	82×55×28
AHV12VN2KV3MAW	−2kV	3mA	11V ~ 13V	$159	82×55×28
AHV12VN2KV5MAW	−2kV	5mA	11V ~ 13V	$169	82×55×28
AHV12VN2KV10MAW	−2kV	10mA	11V ~ 13V	$199	82×55×28
AHV12VN2500V1MAW	−2500V	1mA	11V ~ 13V	$142	82×55×28
AHV12VN2500V3MAW	−2500V	3mA	11V ~ 13V	$159	82×55×28
AHV12VN2500V5MAW	−2500V	5mA	11V ~ 13V	$169	82×55×28
AHV12VN3KV1MAW	−3kV	1mA	11V ~ 13V	$145	82×55×28
AHV12VN3KV2MAW	−3kV	2mA	11V ~ 13V	$149	82×55×28
AHV12VN3KV3MAW	−3kV	3mA	11V ~ 13V	$159	82×55×28
AHV12VN3KV5MAW	−3kV	5mA	11V ~ 13V	$169	82×55×28
AHV12VN3KV10MAW	−3kV	10mA	11V ~ 13V	$269	100×90×30
AHV12VN4KV1MAW	−4kV	1mA	11V ~ 13V	$149	82×55×28
AHV12VN4KV2R5MAW	−4kV	2.5mA	11V ~ 13V	$159	82×55×28
AHV12VN4KV5MAW	−4kV	5mA	11V ~ 13V	$189	82×55×28
AHV12VN5KV1MAW	−5kV	1mA	11V ~ 13V	$155	82×55×28
AHV12VN5KV2MAW	−5kV	2mA	11V ~ 13V	$169	82×55×28
AHV12VN5KV4MAW	−5kV	4mA	11V ~ 13V	$199	82×55×28
AHV12VN6KV1MAW	−6kV	1mA	11V ~ 13V	$159	82×55×28
AHV12VN6KV3MAW	−6kV	3mA	11V ~ 13V	$199	82×55×28
AHV12VN7KV1MAW	−7kV	1mA	11V ~ 13V	$169	82×55×28
AHV12VN7KV2MAW	−7kV	2mA	11V ~ 13V	$239	82×55×28
AHV12VN8KV1MAW	−8kV	1mA	11V ~ 13V	$179	82×55×28
AHV12VN8KV2R5MAW	−8kV	2.5mA	11V ~ 13V	$249	82×55×28
AHV12VN9KV1MAW	−9kV	1mA	11V ~ 13V	$189	82×55×28
AHV12VN10KV1MAW	−10kV	1mA	11V ~ 13V	$199	82×55×28
AHV12VN25KV1MAW	−25kV	1mA	11V ~ 13V	$459	140×100×55
AHV12VN30KVR5MAW	−30kV	0.5mA	11V ~ 13V	$459	140×100×55
ALCHV12VP10KV1MAW	0~10kV	1mA	10 ~ 14V	$269	100×70×30
