Variable Resistor/Capacitor Decade Boxes

In the ongoing development of analog electronic circuits, the routine fine-tuning of RC compensation networks is imperative. Despite the absence of user-friendly resistor and capacitor decade boxes in the market, we undertook the design and fabrication of our own solutions, which have proven highly effective and are now available for our customers.
Introducing the ATRDB12 and the ATCDB12 – both are precision knob-dial type variable resistor and capacitor decade boxes designed for circuits operating up to 1MHz. These devices provide accurate and flexible tuning capabilities.
For applications involving higher frequency circuits, specifically in the range of 1MHz to 10MHz, we engineered the ATRCT101. This compact RC decade mini tuner exhibits significantly lower stray capacitance and inductance, making it an ideal tool for use as a tunable resistor, capacitor, or a resistor-capacitor serial array. This versatile solution caters to the demanding requirements of circuits operating at elevated frequencies.

Noise Measurement Amplifier

Wide adjustable resistance range: 1Ω to 1000kΩ
Wide adjustable capacitance range: 10pF to 10uF
High resistance resolution: 1Ω
High capacitance resolution: 10pF
High accuracy: ±1%
Very comfortable to use and easy to read
Long life time rocker-button switches
Compact size
Durable metal enclosure
100 % lead (Pb)-free and RoHS compliant

Part Number Datasheet With
Pricelist
Buy Now
ATRCT101 Capacitor box buy now buy now

Noise Measurement Amplifier

Wide Adjustable Range: 1pF to 100μF

High Adjustment Resolution: 1pF

High Accuracy: 5%

Compact Size

Durable Metal Enclosure

100 % Lead (Pb)-free and RoHS Compliant

Part Number Datasheet With
Pricelist
Buy Now
ATCDB12 Capacitor box buy now buy now

Noise Measurement Amplifier

Wide Adjustable Range: 0.1Ω to100MΩ

High Adjustment Resolution: 0.1Ω

High Accuracy: 1%

Compact Size

Durable Metal Enclosure

100 % lead (Pb)-free and RoHS compliant

Part Number Datasheet With
Pricelist
Buy Now
ATRDB12 resistor box buy now buy now
